Industrial Cooling Equipment Ltd

"Out of Hours Call Out" to Refrigeration Breakdown on Pharma 2-8C Coldroom

Pharmaceutical Manufacturer

Location

North Wales

Date

July 2023

Value Range

Under £1,000

Product Category

Service & Repair

See more case studies

Multiple 2°C to 8°C MHRA Chillstores for Pharmaceutical Storage

Design, supply & installation of multiple Walk In Pharmaceutical Chillstores, each with an operating range of 2°C to 8°C.

Read More

Replacement of DX Air Conditioning with Evaporative Cooling

See how we saved a food manufacturing client over £9,000 a year in energy costs

Read More

Emergency “Out of Hours Call Out” to Pharma 2-8C Coldroom

ICE Ltd the experts in Refrigeration, provide a case study of an “Out of Hours” refrigeration breakdown for a 2-8C Pharma Coldroom.

Read More

Installation of New Air Conditioning System to Three New Server Rooms

Our longstanding pharmaceutical client required cooling to three server rooms at their new state of the art distribution facility in Wakefield.

Read More

Maintenance Visit to Walk In Freezer

ICE Ltd the experts in Refrigeration, provide a case study of Freezer Maintenance Contract for a Kitchen Manufacture in Runcorn

Read More

Maintenance Contract to Free Coolers

Free Cooler Maintenance Contract for Water Treatment Manufacturer based in Cheshire

Read More

A Pharmaceutical Manufacturer based in North Wales who have held a maintenance contract with ICE for over 20 years, had a refrigeration breakdown on both run & standby systems that’s serve a 2-8C Pharma Coldroom.

With product stored in the room worth millions, it was a race against time to save the room and the product before the 8C limit is reached.

Scope of work

The call out was late on a Sunday evening and as the site currently holds a maintenance contract with ICE, they are provided with 24/7/365 emergency support.

ICE needed to arrive to the refrigeration breakdown within 4hrs, to diagnose the issue and get one of the systems back on line before the temperature mapped room reached the 8C limit.







How ICE helped

The sites maintenance technician called our “Out of Hours” call out number and requested to be put through to the “On Call” engineer. An engineer was dispatch immediately and advice was provided over the telephone to stop all access to the room and to switch off any lighting and other sources of heat gain.

The engineer arrived onsite within 2 hours of the initial call to find System 1 with a large leak on the suction line and System 2 with a ceased compressor.

The leak on System 1 was repaired and the system was pressure tested and recharged with refrigerant from site stock. The room was back operational before exceeding the deviation temperature limit of 8C.

After using all the site stock of refrigerant on the repair, more refrigerant was collected from our stores by another engineer and delivered to site.

A new compressor was ordered for System 2 and fitted the following day.

Results

Following the repairs ICE investigated why both run and standby systems failed, it was found that the major leak on one system caused the room to switch over to the backup system and on switch over the compressor failed on start up. Within days of the visit both systems were back operation with full run and standby facility reinstated. The rapid response from our Service Team saved the client millions in potentially lost product.

Note: The above 24/7/365 “Out of Hours” call out service is available to our Maintenance Contract Customers ONLY.
